Track & Trace Solution-Stretchwrapping

» Two cameras take a image at the sametime. One camera inspect bundle Label, other camera reads all Codes
inside the bundle.

Track & Trace Solution Full-Overwrapping

» First camera identifies all codes in bundle.
» Labeler applies bundle label.
» One camera captures one code out of bundle and one camera verifies bundle label

Track & Trace Solution Full-Overwrapping

» First Camera checks each individual carton.
» Next camera checks sequence of codes in bundle.
» Labeler applies bundle label.
» One Camera captures one code out of bundle and one camera verifies bundle label

Track & Trace Solution - Side loading case packer

» All codes get inspected after Layer is pushed into Case
» Labeler applies case label
» Case Label is inspected by second camera

Track & Trace Solution - Top loading case packer

» Camera reads code of each product individually.
» Trigger for camera via servo position.
» Labeler applies case label
» Case label is inspected by second camera.

Track & Trace Solution - Top loading case packer

» Codes of one entirerow are checked by camera
» Labeler applies case label
» Case label is inspected by second camera

Track & Trace Solution - Top loading case packer

» Labeler applies case label
» Case label is inspected by second camera

Track & Trace Solution - Palletizer

» One camera checks case label
